General Information
Brand
Klein Tools
Part Number
1649920
Product Type
Parallel Jaw Grip
Application
Wire Pulling
Packaging
Retail
Country of Origin
United States
UPC
092644470776
California Residents
Physical Characteristics
Length
13.1 (33.3 cm)
Width
3.06'' (7.8 cm)
Height
9.3'' (23.6)
Weight
3.76 kg
8.30 lb
Color
Black / Brass
Finish
Black Oxide Finish
Material
Steel
Diameter
0.68'' to 1.42'' (17.3 to 36.1 mm)
Details
Size
Maximum Safe Load: 12000 lb (5443 kg)
Hot Latch: Yes
Swing Latch: No
Spring: Yes
Locking Handle: Yes
Hot Latch: Yes
Swing Latch: No
Spring: Yes
Locking Handle: Yes
Grip Type
Ergonomic
Jaw Opening
Round
Jaw Length
4.85'' (12.3 cm)
AWG
ACSR, AAC and Bare Copper
Features
Cable pulling grip securely pulls ACSR, AAC and bare copper cables
Holds cable sizes from 0.68-Inch to 1.42-Inch (17.3 to 36.1 mm)
Includes a latch to help maintain cable position in the grip jaw
Fine tooth jaw geometry provides greater grip strength
Made in the USA
Innovative hot latch with V-notch centers cable
Spring closes grip on cable to hold the initial position
Large opening in the handle accommodates a wide variety of hooks on hoists, winches and tackle blocks
Max Safe Load of 12000-Pound (5443 kg)
Patent pending design
Holds cable sizes from 0.68-Inch to 1.42-Inch (17.3 to 36.1 mm)
Includes a latch to help maintain cable position in the grip jaw
Fine tooth jaw geometry provides greater grip strength
Made in the USA
Innovative hot latch with V-notch centers cable
Spring closes grip on cable to hold the initial position
Large opening in the handle accommodates a wide variety of hooks on hoists, winches and tackle blocks
Max Safe Load of 12000-Pound (5443 kg)
Patent pending design
