General Information
Manufacturer
Klein Tools
Part Number
16845CAT
Product Type
Chicago Grip Wire Pulling
California Residents
Specifications
Material
Alloy Steel
Size
Cable Diameter: 0.218'' to 0.55'' (5.54 to 13.97 mm)
Length
Jaw Length: 5'' (127.0 mm)
Weight (Approximate)
6.9 lb (3.1 kg)
Miscellaneous
Features
Aggressive sawtooth jaw profile resists build-up from galvanized coating on guy strand and EHS cables
Equipped with chain, toggle and shackle to keep grip from falling off the cable
Designed for cable sizes 0.218 to 0.55-Inch (5.54 to 13.97 mm)
5-Inch (127 mm) jaw length for extra gripping area on stranded cable
Spring closes grip on cable helping to maintain initial position
Locking handle keeps jaw open while grip is placed on cable with a hot stick
Maximum Safe Load is 8000-Pound (3629 kg)
Equipped with chain, toggle and shackle to keep grip from falling off the cable
Designed for cable sizes 0.218 to 0.55-Inch (5.54 to 13.97 mm)
5-Inch (127 mm) jaw length for extra gripping area on stranded cable
Spring closes grip on cable helping to maintain initial position
Locking handle keeps jaw open while grip is placed on cable with a hot stick
Maximum Safe Load is 8000-Pound (3629 kg)
Country of Origin
USA
